982 Semi Automatic Glue Dispenser, AC 110v Solder Paste Liquid Adhesive Controller Dropper Machine Glue Dropper Glues Liquid Adhesive Dispenser 0.01-30s Timer Controlled

DescriptionAre you affected by the slow speed of traditional drip glue, which affects productivity? Are you often wasting a lot of glue material? Do you feel that the precision of glue dripping is low and difficult to control? Choose this semi-automatic glue dispenser machine, which can precisely control the dripping speed and improve the working efficiency, bringing you a more efficient and energy-saving working experience!SpecificationColor: BlackModel: 982Material: MetalSpitting Mode: Manual / Semi-automaticMinimum Drip Volume: 0.01mlSpitting Time Interval: 0.1-9.9sAutomatic Timing(Can Be Set): 0.01-30s Repeat Accuracy: ±0.5%Internal Voltage: 12-24DCInput Air Pressure: 2.5-7bar(35-100psi)Output Air Pressure: 0.1-5.5bar(1-78psi)Power Supply: 110V AC, 60Hz Power Consumption: 20WPlug Specification: American Standard 110VProduct Size:23*15*6cm/9.05*5.9*2.36inPackage Size:20*26*14cm/10*9*12.5inGross Weight: 2.1kg/4.63 lbsPackage Included1* Dispenser Main Unit1* Manually Switch1* Foot Switch1* Air Tube1* Connection Tube1* Power Cord1*Dispenser Stand2* 30CC Liquid Barrels6* Dispensing Needles1* Chinese and English ManualNotes: 1.The input high pressure should not exceed 7 bar (100psi), and the maximum working pressure of the glue dropper should not exceed 5.5 bar (78psi). If the working air pressure is above 4 bar, please switch to aluminum connectors.2.If available, store all materials at a constant temperature (5°) as directed to ensure that the concentration does not change significantly during use.3.When the material concentration is too large (flow difficulties), can not drip, if you want to use it, according to the manufacturer's instructions dilute the use; before work, the material must be fully stirred evenly to ensure that the size of the drip consistent.4.Automatic state, the general air pressure adjustment in the machine at 1-2.7bar (15-40psi) is more appropriate. When working in the automatic state, the strength of the vacuum tube pumping back air should be adjusted to the proper position. Too much pumping back will flush the piston and destroy the normal operation. 5.Automatic state work, according to the actual situation, timely removal of the material left at the needle nozzle, these materials gradually curing will block the muzzle discharge and back pumping; after work, the barrel should be cleaned in time, otherwise, the barrel's disassembly will be very difficult.6.Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement and make sure you do not mind before ordering.

• 【Robust and Durable】This glue dispenser is made of metal, ensuring robustness and stability against damage and corrosion. It utilizes a fourth-generation chip-based circuit board design, significantly enhancing stability. Equipped with a high-quality electronic valve, it offers some leak-proof protection, ensuring operational safety and effectively extending the lifespan of the semi-automatic dispensing machine.
• 【Vacuum Back-Suction】This solder dispenser features a vacuum back-suction device, effectively preventing glue dripping during use, achieving more precise dispensing, and ensuring a clean working environment. It is suitable for most yellow glues, fast-drying adhesives, epoxy resins, etc., and is widely used for bonding various electronic components, machinery manufacturing, instruments, jewelry, and other items.
• 【Stable and Efficient】This glue adhesive dispenser uses a high-quality electronic valve that can instantly activate the diaphragm valve, increasing work efficiency by over 80%. It employs a high-end all-copper coil transformer, stabilizing voltage changes and extending service life. Suitable for high-frequency, high-intensity working environments, it improves operational safety while also offering high efficiency and energy savings.
• 【Precise Dispensing】This 982a auto glue dispenser has a minimum dispensing volume of 0.01 ml, a dispensing interval of 0.1-9.9 seconds, and precise dispensing with a repeatability of approximately 0.5%. It also features a single-hole manual control switch for convenient manual operation, enabling more precise and timely dispensing.
• 【Thoughtful Design】This air tube glue adhesive dispenser can achieve automatic dispensing by machine or precise control using the single-hole manual switch. For hands-free operation, the switch can be set to automatic mode for a more efficient and higher-quality workflow. Its high-precision air pressure gauge accurately controls the air pressure input to the air pump and precisely converts the pressure, ensuring the air hoses will not rupture.
